SYSTEM WIRING DIAGRAM
IGNITION
STARTER
SWITCH
PARKING
LIGHTS
(+/-) On-Board Relay
BATTERY
-
BLACK/WHITE
15A On-board
WHITE/RED
GRAY
CUT
IGNITION
+
SWITCH
+ CAR-JACK ENABLE
OUTPUT
(-)HOOD/TRUNK TRIGGER SWITCH
SIREN
(-) ARMED
(-)DOOR TRIGGER SWITCH
+ DOOR TRIGGER
PINK
VIOLET
FUSE
POLARITY SELECT UNLOCK(87)
GREEN
POLARITY SELECT LOCK(87)
BLUE
UNLOCK OUTPUT(30)
Siren + 2A MAX
BROWN
UNLOCK SWITCH(87A)
LED
BATTERY +
LOCK SWITCH(87A)
+ 10A MAX
RED
WHITE
+ SWITCHED IGN "ON"
LOCK OUTPUT(30)
(-) 500MA
ORANGE
YELLOW
N/O
N/C
BLACK
GROUND
VALET/PROGRAM
SWITCH
VIO/WHT
COMMON
VIOLET
WHITE
GRAY
GREEN
BLUE
N/O
N/C
SHOCK SENSOR
DUAL-STAGE
SENSOR 2
OPTIONAL
CS-2004DC
CS-2004TW1
CS-2004TW1 Antenna
BLACK 3-PIN
BROWN/WHITE
(-)HORN
OUTPUT
PORT
Series II
(-) REMOTE
OUTPUT 2
RED/BLACK
(-) REMOTE
OUTPUT 1
BROWN/BLACK
(-) DOME LIGHT
ILLUMINATION
ORANGE/BLACK
relay output (30)
input source (87)
On-board relay
coil input (85)
