SONY
DESCRIPTION: Dolby- Digital POWER
STR-DA3ES
DIMENSIONS
Receiver
(WHD):
17
" x 6 7/8" x 18 1/4"
W
E|
GHT:
Approx: 54 lbs
FRONT VIEW
REQUIREMENTS:120VA'
POWER
60Hz
CONSUMPTION: 5
00
Watts
1/2"
6 7/8"
6 1/4"
1/2"
17"
SIDE VIEW
18
1/4
"
5/8"
1
1
/
8
"
2
"
3
10
1
/
2
"
BACK VIEW
2
"
1
5
/
8
"
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES IN
THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 986 3062 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
