SONY
ST-SA50ES
DESCRIPTION^_______AM/FM TUNER POWER
DIMENSIONS
REQUIREMENTS: 12QV
(WHD):
16 7/8" X 3 3/4" X 14 1/8"
POWER
6QH
WEIGHT:
19bs 3oz
CONSUMPTION:
13
Wa
1/4 inch = 1 inch Scale 4:1
FRONT VIEW
16 7/8"-
3/8"
3 3/4"
2
"
<
■<---
3/8"
SIDE VIEW
5/8"
3/8"
BACK VIEW
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
1
