HOW TO CONNECT THE DRAIN HOSE
IN CASE OF PUMP-DRAINED WASHER
IN CASE OF GENERAL WASHER
1. After pressing the joint ring, insert to the drain hose.
2. After direoting the drain hose to a drain, join to the
drainoutiet of the washing maohine.
* •
drain-outiet
3. Be sure to join them tightiy by pressing the joint ring and
pushing it into the drain-outiet.
• The iength of drain hose is adjustabie so that you oan
extend the iength appropriateiy.
16_installation & maintenance
