Getting Started

Hooking up the Turntable

The phono cables and earth lead come attached to the

rear of the cabinet.

1

Connect the cable with the red plug to the right
PHONO IN R input jack on the amplifier and
connect the cable with the white plug to the left
PHONO IN L input jack.

Amplifier

2

Set MM. AMP. on the bottom panel according to
the amplifier connection as follows:

For connection to

Set MM.AMP. to

PHONO IN jacks

OFF

AUX IN or LINE IN jacks

ON

Mains lead hookups

Connect the mains lead to an AC wall outlet after
completing all of the previous connections.

in______ si

1 1

A

r,

--------

to a wall outlet
