Page 10 SKU 96405 For technical questions, please call 1-800-444-3353.
recoMMended MiniMuM wire gauge For eXTension cords*
(120/240 VolT)
naMeplaTe
aMperes
(at full load)
eXTension cord lengTh
25 Feet 50 Feet 75 Feet 100 Feet 150 Feet
0 – 2.0 1 1 1 1 16
2.1 – 3.4 1 1 1 16 14
3.5 – 5.0 1 1 16 14 12
5.1 – 7.0 1 16 14 12 12
7.1 – 12.0 1 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
Table a * Based on limiting the line voltage drop to five volts at 150% of the rated amperes.
symbology
Double Insulated
V~
Volts Alternating Current
Canadian Standards Association
a
Amperes
Underwriters Laboratories, Inc. n0 xxxx/min.
No Load Revolutions per Minute
(RPM)
