CHECK
OWNER S MANUAL
,
OBD2 CODE READER
5
• Small in size and conveniently fits in your palm
• Specially designed for DIYers and car-owners
• Safely communicates with the on-board computers
• No batteries needed-powered via OBD II cable
• One-year warranty
2.3 Vehicle Coverage
The T45 VW/AUDI Code Reader is specially designed to work with
most Volkswagen and Audis sold Worldwide of 1990 or newer models.
If a VW/AUDI has a 16-pin "OBD-II style" Data Link Connector(DTC),
the code reader will certainly work. If it has an old-style 2x2 Data Link
Connector(DTC), then it depends on whether there are 4 or 3 wires
connecting to the pins. If there are 4 wires, each connecting a pin, then it
will work. If there are only 3 wires, leaving one pin disconnected, then it will
not work .
3. Operating Instructions
CAUTION: Don’ t connect or disconnect any test equi pment with ignition
on or engine running.
1. Turn the ignition off if it is on.
2. Locate the 16-pin Data Link Connector (DLC), and plug into the Code
Reader cable connector.
3. Wait for the LCD display to read “VW AUDI T45 ”.
4. Turn the ignition on. But do not start the engine.
5. When the display indicates "1.ENGINE", press and release the ENTER
button. An "READY" message is observed on the display. Then press
and release the "ENTER" button again, another "SCAN..." message is
VW AUDI
T45
