Crimestopper Security Products RS-850 - Manual (Page 15)

TRANSMISSION
PROGRAM/
OVERRIDE
PARKING
LIGHTS
SWITCH
ECU
RS-850
ANTENNA/
RECEIVER
PLUG
LED
COIL
+ -
(-) UNLOCK OUTPUT
+12 V FOR RELAYS
12A MAX.
(-) LOCK OUTPUT
ENGINE
ECU
GREEN
BLUE
RED
WHITE
FUEL
PUMP
PINK
RED
H/V/AC CONTROL
BROWN
GRAY
RED
YELLOW
(-)IGN OUT
IGN 1
RED/WHITE
TACH INPUT
ORANGE/BLACK: (-) OEM DISARM
(-) HOOD SWITCH
GRAY
(+12V) BRAKE PEDAL RESET
BLACK
PURPLE
ORANGE: (-) OEM REARM
30
85
YELLOW/BLACK
(+12V) GLOW PLUG INPUT
PINK
NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT
YELLOW/WHITE
(-) START ACTIVATION
GREEN
87
86
(-) IGN2 / ACC OUT
(GREATER THAN 30A) IGNITION CIRCUITS.
ACC
2nd IGN 1
FUSED
GROUND
12V
+
FUSE
FUSE
30A
TACH
30A
1
2
0
3
4
(If necessary)
TO SECOND ACC
5
STARTER DISABLE
6
(-) ANTI-GRIND/
RELAY OUTPUT
7
8
+
BATTERY
DIESEL (+12V) WAIT
TO START LAMP
RS801 - TO KEYLESS
ENTRY SYSTEM OR
STARTER
ALARM AUX. OUTPUT
WAIT
-
+
FUSED
12V
30
85
87
86
ANTENNA
TO
(If necessary)
