Rear View Safety Pro Tips for Sprinter Chassis third brake light
camera installation:
1. Always use our supplied camera cable from the rear to the monitor
2. You will find clean power hook-ups under the driver seat area to
power our RVS monitor offerings. Determine positive and negative
hook-ups are correct
3. Our multiplex box can accept (2) more cameras and has default
wires for turn signals if required. Under the driver seat is the best
place for the left and right turn signal default hook up
4. There are two approved locations to pick up the reverse wire.
A. The BEST place to tap the reverse trigger is located in the rear of
the coach in the rear pillar at the bottom grey plastic cover. There is a
4 pin connection for the tail lights. Strip off a little insulation of the
reverse wire, attach a reverse wire, then loom that reverse wire along
our camera cable to the multiplex box
B. If you are not using our monitor with multiplex box, you can open
the hood of the Sprinter, take the cover off the fuse block and get the
reverse trigger off the blue wire.
