Reverse With Confidence
™
Rear Camera Specifications
Camera
1/4” Sharp® Color CCD
Picture Elements
250,000 pixels
Gamma Correction
r=0.45 to 1.0
Image Sensor 480TV lines PAL:500h x 582v,
NTSC: 510h x 492v
Lens
2.1mm
View Angle
130°
Sync System
Internal Synchronization
Infrared distance
50 Feet (18 Infrared IR)
Usable Illumination
0 Lux (IR On)
Power Source
DC 12V-24V (+/- 10%)
S/N Ratio
More than 48dB
Electronic Iris
1/50, 160-1/100,000sec
Video Output
1Vp.p 75ohm
IR Switch Control
ACDS Automatic Control
Impact Rating
20G Vibration/100G Shock
Operating Temperature
-30C - +60°C/RH 95
%
Max
Storage Temperature
-30°C - +70°C/RH 95
%
Max
