Rear View Safety
10
Installation Guide
F Infrared technology built
into camera IRs are activated
automatically according to the
lighting conditions.
F When using the postive trig-
ger functions (blue, yellow &
white wires) each trigger
function needs to work on a
seperate 12V+ source i.e. the
Yellow and White wires can be
wired to a turn signal circuit
etc.
F Grid lines function can be
turned on/off by manually
from menu. (See page 13)
Monitor
1. To Attach the Pedestal mount to the dashboard or to the headliner use self-tapping
screws and/or the adhesive pad.
2. Attach monitor to mount, and adjust mounting angle to allow optimum driver
viewing comfort. (see figure 1.1 on page 11)
Note: If connecting power
directly to battery, the camera
is always ON and therefore can
drain battery. Therefore it is
recommended to connect
power to an ignition switched
accessory power source.
