QHYCCD IMG132E User Manual

Page 8

favorite-Quality the filter Setting: Slider set to retain

image quality, low-quality images can be filtered and removed

the atmospheric jitter impact on image quality, suitable for

astrophotography.

the camera Setup-color/mono: Different cameras have

different Bayer Pattern. We can choose a different Bayer Pattern, to

get the right color. RAW (Mono), do not use the Bayer Pattern, image

monochrome.

the camera Setup-other setting-offset: The

adjustment range is 1-100. Slight backlight compensation on the

image, to increase the overall brightness of the image, to avoid the

darkest pixel value less than 0.

Screen the Zoom: Adjust the screen aspect ratio. Note that

this setting is only to change the display ratio do not to change the

size of footage.

language: Select the display language.

help: Display help on the information.

2.4 histogram

hiSt: When selected, it will display a standard histogram of the

photo. Both, the dark and the bright parts of the image, along with

white balance can be analyzed with great accuracy.

oSc: Waveform

birD: Full map preview.

2.5 Display lut

There are four kinds of default processing of predefined data

processing in real time image processing mode: False Color,

Thermal Picture, Black/OverExposure and Negative, the users can

select any of them as needed. This additionally allows three kinds

of customer defined custom modes. Photoshop and other graphic

image software editors along with their corresponding reference

articles are set to install in the LUTMAP folder.

black/over exposure: Use this mode on the overexposed

areas shown in red, underexposed areas are blue features, you can

adjust the GAIN/offset value for the regulation to obtain a normal

exposure picture.

2.6 other menu bar options:

timeStamp Show: When this feature is selected, the

timestamp will be displayed on the screen.

favorite-Show the oSD: Select the function on the screen

will display the OSD box.

favorite - high priority Disk write: This is part of the

small memory of the graphics to make improvements. You can

reduce the display frame rate, slower graphics to ensure that the

file's writing speed.
