02 01
Welcome to QHYCCD astronomical products.
The IMG 132E is a high sensitivity planetary camera, incorporating a
Sony Exmor CMOS sensor. In a short period of time it can capture
the details of faint celestial objects. Even at high gain settings, the
IMG 132E will not have the horizontal or vertical stripe interferences.
Its high frame rate and low noise characteristics will allow the
users to easily obtain clearer celestial images. Two resolutions are
supported: 1280 × 1024 and 640 × 480, with frame rates up to 25
and 86 fps. [Note 1] .
The IMG132E features a 32MByte SDRAM image buffer, so, you can
get a smooth image display.
The IMG132E supports EZplanetary imaging software. In addition,
for WDM video, a driver is supplied which can be used in the field of
HD video chat, webcast video conferencing networks, and industrial
applications. The latest software updates for the camera are
available at: http://www.qhyccd.com/download.html for download.
Before using the camera, please read this manual carefully in order
to quickly master the proper use of this product. Always observe any
recommend precautions when using the product.
For technical support, please contact your local QHY dealer, or call
us at: 010-82428727 (Chinese), or, log onto www.qhyccd.com /
contact.html (English) for guidance and answers.
camera Specification table proDuct introDuction
CMOS Chip SONY Exmor CMOS IMX035
CMOS Size 1/3 Inches
Pixel Size 3.63×3.63um
Supported Resolution 1280Ч1024; 640Ч480
Image Area 4.6×3.7mm
Quantum efficiency 61% @ blue; @ 63% green; @ 54% red
Readout Type Progressive Scan, Rolling Shutter
frame Rate 1280x1024 @ 25 FPS; 640 × 480 @ 86 FPS
ADC 12 (8 Outputs)
Internal Cache 32MByte
USB Interface USB2.0 High Speed Interface
Telescope Interface M42 (M) to 1.25 Inches
IR Cut filter Yes, Can be Removed to Replace with Other
filters [Note 2]
Weight (Body Only) 166 g
Size 78Ч62Ч28mm
Intercept 12.7mm
Power Supply USB-Powered
Note 1: Dependant upon computer speed.
Note 2: The filter removal and replacement details are provided in the manual page 07 or
contact your product regional agent / QHYCCD technical support.
caution: Before you attach IMG 132E to your
computer for the first time, you must install the software
as Page 04! If you reinstall system or uninstall the driver,
please do it again!
