Pinnacle Products reserves the right to make any changes in materials, specifications, prices or design without notice.

Pinnacle Products may also discontinue items at any time.

Replacement Parts

© 2013, Pinnacle Products International, Inc.

6

Portable Air Circulator User’s Manual

NEVER LEAVE A FAN

UNATTENDED WHILE

OPERATING OR WHILE

CONNECTED TO A POWER

SOURCE

Models:

Item #

Description

PT-36-BDF-A

PT-36-BDF-AF

PT-42-BDF-A

PT-42-BDF-AF

PT-48-BDF-A

PT-48-BDF-AF

1

Hardware for Guards

90-032-0005

90-032-0005

90-032-0005

2

Front Guard

90-032-0560

90-032-0570

90-032-0580

3

Fan Blade Assembly

90-003-1025

90-003-2025

90-003-5225

4

Power Switch Holder

90-016-0100

90-016-0100

90-016-0100

5

Capacitor

90-004-0100

90-004-0100

90-004-2500

6

Power Switch

90-025-0100

90-025-0100

90-025-0110

7

Handle / Cord Wrap

90-006-0150

90-006-0150

90-006-0150

8

Frame

N/A

N/A

N/A

9

Mount Bar

90-009-0260

90-009-0270

90-009-0280

10

Serial Number Plate

N/A

N/A

N/A

11

Power Cord

90-026-0050

90-026-0100

90-026-0100

12

Rear Guard

90-032-0565

90-032-0575

90-032-0585

13

Belt

90-037-0400

90-037-0450

90-037-0450

14

Fan Pulley

90-034-0300

90-034-0350

90-034-0350

15

Bearing Plate

90-013-0100

90-013-0100

90-013-0100

16

Motor Pulley

90-035-0350

90-035-0350

90-035-0355

17

Fan Shaft

90-003-0750

90-003-0750

90-003-0755

18

Bearing E-Clip

90-065-0210

90-065-0210

90-065-0210

19

Fan Pulley E-Clip

90-065-0220

90-065-0220

90-065-0220

20

Bearing

90-040-0100

90-040-0100

90-040-0100

21

Bearing Housing

90-013-0200

90-013-0200

90-013-0105

22

Leg

90-002-0480

90-002-0480

90-002-0450

23

Pneumatic Wheel

90-008-0300

90-008-0200

90-008-0200

24

Wheel Axle

90-008-0470

90-008-0480

90-008-0480

25

Motor

90-030-0725

90-030-0825

90-030-0925

26

Motor Support

N/A

N/A

N/A

27

Wavy Spring Washer

90-066-0001

90-066-0001

90-066-0001
