NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A FUEL SOURCE
© 2013, Pinnacle Products International, Inc. Propane Tank Top Heater User’s Manual
®
Parts list
Item
#
'HVFULSWLRQ
PT-16-TTC PT-32-TTC PT-47-TTC
1 Regulator Assembly 20-032-0001 20-032-0002 20-032-0002
2 Hose Assembly ௅
3 Manifold Assembly ௅ 20-111-0020
4 Safety Valve Assembly 20-013-0001 20-013-0001 20-013-0001
Burner Assembly 20-023-0003 20-023-0003 20-023-0003
6 Front Guard 20-101-0001 20-101-0001 20-101-0001
7 Thermocouple 20-091-0002 20-091-0002 20-091-0002
8 Tank Collar Bracket
௅
9 Mounting Bolt Knob
௅
10 Rear Guard 20-101-0002 20-101-0002 20-101-0002
11 Manifold Bracket - A
௅
20-111-0002
௅
12 Manifold Spring
௅
20-111-0003
௅
13 Manifold Bracket - B ௅ 20-111-0004 ௅
14 Nozzle
MPU Lead Wire - A
16 MPU Lead Wire - B ௅ ௅
17 Wing Bolt 20-111-0006 20-111-0006 20-111-0006
18 Tipover Switch Bracket
19 Tipover Switch
20 Wind Cover
21 Swivel Bracket - A
௅ ௅
22 Swivel Bracket - B
௅ ௅
23 Swivel Bracket - C ௅ ௅
24 Swivel Bracket Bolt ௅ ௅
Elbow ௅ ௅
26 Burner Assembly Hose ௅ ௅
27 Wing Bolt ௅ ௅
28 Bushing ௅ ௅
29 Plane Washer
௅ ௅
13
