NEVER LEAVE HEATER UNATTENDED WHILE
CONNECTED TO A POWER SOURCE
© 2014, Pinnacle Products International, Inc. Turbo Electric Fan Heater User’s Manual
®
Maintenance
Cleaning and Maintenance
– Before cleaning the appliance, disconnect it
from the outlet and let it cool down.
– The enclosure is easy to get dirty. Wipe it
often with a soft sponge. For very dirty parts,
wipe with a sponge dipped in < 122°F water
and mild detergent, then dry the heater
enclosure with a clean cloth. Be careful not to
let the water enter the inside of the appliance
– In order to protect the enclosure, do not
splash water onto the heater, and never
use a solvent like gasoline, isoamyl acetate,
toluene, etc. to clean the heater.
Operation
Grounding Instructions
PT-515-120:
– This heater is for use on 120 Volts. The
cord has a plug as show at A (below). An
adapter as shown at C is available for
connecting three-blade grounding-type plugs
two-slot receptacles. The green grounding
lug extending from the adapter must be
connected to the permanent ground such as
a properly grounded outlet box. The adapter
should not be used if a three-slot grounded
receptacle is available.
PT-53-240:
– This heater is for use on 240 (or 208) volts.
The cord has a plug as shown in D (below).
No adapter is available for this blade
configuration, and none should be used. The
type outlet is a 240 (or 208) volt grounding
outlet. When properly installed, it provides a
ground connection through the cord to the
heater to protect the operator from electric
shock.
8
B
A D
C
Grounding Means
Grounding Pin
Metal Screw
Grounding Methods
Figure 2
