NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2014, Pinnacle Products International, Inc. Oil Fired Radiant Heater User’s Manual 4
Assembly Instructions
PT-70-SS-A
What’s In The Box
Carry Handle (1) Black Screws (2)
Carry Handle Assembly
1. Align holes in the upper housing with the 2
holes in the handle as shown in Figure 2.
2. Insert screws and tighten firmly.
Tools Needed:
- Phillips Head Screw Driver
Figure 2
- Remove the heater and all packaging materials
from the shipping carton.
Note: Save the box and packaging materials
for future storage.
Figure 3
Attach the handle while still in the box
for easier unpacking. (See Figure 3)
