NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2014, Pinnacle Products International, Inc. Oil Fired Radiant Heater User’s Manual 13
Parts List
Item # Description PT-70-SS-A
1 Fuel Tank Assembly 75-001-0350
2 Oil Filter Assembly 75-023-0270
3 Fuel Pipe 75-023-0345
4 Fuel Packing 75-023-0355
5 Fuel Hose 75-024-0510
6 Fuel Gauge Assembly 75-022-0210
7 Fuel Cap Assembly 75-002-0110
8 Cooling Fan Housing 75-011-0670
9 Operating Switch 75-012-0110
10 Operating Switch Wire Assembly 75-012-0220
11 Rear PCB Assembly 75-013-0200
12 Electronic-Pump Assembly 75-027-0250
13 Ignitor 75-025-0120
14 Main PCB Assembly 75-025-0400
15 Tip-Over Sensor 75-051-0200
16 Tip-over Sensor Wire Assembly 75-051-0260
17 Cooling Motor Assembly 75-047-0250
18 Cooling Fan 75-047-0200
19 Shell 75-011-1000
20 Handle 75-001-0060
21 Shell Insulator 75-011-1100
22 Temperature Limit Switch 75-040-0100
23 Chamber Assembly 75-035-0800
24 Chamber Insulator 75-035-0820
25 Ceramic Fiber 75-035-0830
26 Heat Plate 75-012-0600
27 Shell Ring 75-011-0650
28 Safety Guard 75-012-0310
29 Burner Body 75-036-0180
30 Spark Plug 75-075-0200
31 Burner Blade 75-036-0120
32 Nozzle 75-036-0400
33 Nipple 75-040-0610
34 Diffusion Cap 75-036-0500
35 Blower Motor Assembly 75-045-0200
36 Photocell Assembly 75-038-0200
37 Back Cover 75-013-0105
38 Power Supply Cable Assembly 75-032-0186
39 Electrical Outlet Assembly 75-029-0100
40 Return Pipe 75-055-0100
41 Return Hose 75-055-0200
42 Electronic Pump Bracket 75-027-0255
43 Heat Shield 75-012-0320
