Stability bracket
We recommend a stability bracket is fitted to the cooker.
The type shown in fig. 35 can be purchased from most plumbers merchants and do it
yourself (D.I.Y.) shops.
Wall fixing
Floor fixing
Dimension is in millimetres
3
Outline of cooker
backplate at the
engagement slot
Fig. 35
Brackets
Existing
slot in rear
of cooker
Dotted line showing the
position of cooker when fixed
