Manual No. 4801-5035 Rev 2-09 PolarCool Page 8 of 26
5.2 Unpacking PolarCool
IMPORTANT!
Remove Tape From Float Before Operating!
Follow Instructions Below.
INSTRUCTIONS:
1. Carefully unpack PolarCool from shipping carton.
2. Lift Cover to gain access to pads as shown in Diagram 1 at right.
Tilt pads as shown. Remove pads to access float.
3. Float is securely taped to bottom of PolarCool for shipment.
USE HAND AND APPLY PRESSURE TO HOLD FLOAT IN PLACE.
CAREFULLY PEEL TAPE FROM FLOAT WITH OTHER HAND! DO
NOT BEND FLOAT ARM WHILE REMOVING TAPE! See Diagram 2.
4. Replace pads. Look for arrows on side of pad as shown in Diagram 3. Ensure
pads are replaced with up arrow pointed UP.
Diagram 1
Diagram 2
Float Shown Ready For Operation
Diagram 3
FLOAT
PUMP
LOW
LEVEL
SWITCH
Low Level
Switch
(Only on 18”
and 36”
Variable
Speed
Models.
