PIMs and BRIMs
4-6 Port Interface Modules
Table 4-1 provides basic information regarding the available PIMs and the
connectors, media, and technologies they support.
Table 4-1. PIM Reference Table
PIM Technology Media Connector
EPIM-A Ethernet AUI DB15 (Male)
EPIM-C Ethernet Thin Coaxial RG58
EPIM-F1 Ethernet Multimode
Fiber Optics SMA
EPIM-F2 Ethernet Multimode
Fiber Optics ST
EPIM-F3 Ethernet Single Mode
Fiber Optics ST
EPIM-T Ethernet UTP RJ45
EPIM-X Ethernet AUI DB15
(Female)
Fast Ethernet Interface
Module-100TX Fast Ethernet UTP RJ45
Fast Ethernet Interface
Module-100FX Fast Ethernet Multimode
Fiber Optics SC
Fast Ethernet Interface
Module-100F3 Fast Ethernet Single Mode
Fiber Optics SC
Fast Ethernet Interface
Module-100FMB Fast Ethernet Multimode
Fiber Optics SC
TPIM-F2 Token Ring Multimode
Fiber Optics ST
TPIM-F3 Token Ring Single Mode
Fiber Optics ST
TPIM-T1 Token Ring STP DB-9
TPIM-T2 Token Ring UTP RJ45
TPIM-T4 Token Ring UTP RJ45
