System Configuration and Connectors 2–1
2
System Configuration and Connectors
This chapter describes the AlphaPC 164SX configuration, board connectors and
functions, and switch functions. It also identifies switch and connector locations.
The AlphaPC 164SX uses switches to implement configuration parameters such as
system speed and boot parameters. These switches must be configured for the user’s
environment. Onboard connectors are provided for the I/O interfaces, DIMMs, and
serial and parallel peripheral ports.
Figure 2–1 shows the board outlines and identifies the location of switches, connec-
tors, and major components. Table 2–1 lists and defines these items.
