About Your Modem 1-1
About Your Modem
Back Panel
To find out more about getting your modem quickly connected, see Chapter 2, “Installing Hardware”.
Figure 1-1 The jacks and connectors on your Modem.
Telephone Line jack
RS232 Connector
Power Adapter Connector
On/Off switch
