PIP Settings

PIP Mode

When PIP/PBP
activated

PIP Source

This function brings up a window displaying image from another input source.

PIP/PBP submenu when PIP/PBP OFF (main source is VGA/DVI-D input)

PIP/PBP submenu when PIP/PBP ON (main source is VGA/DVI-D input)

NOTE:

When using DVI source, the contrast adjustment is not available.

There are two modes: Picture in Picture (PIP) and Picture by Picture (PBP)

Use

and

to browse and

to select "Off", "PIP" or "PBP".

When PIP/PBP is activated, select "Swap" to exchange the input source for the main screen and PIP/PBP window.

Select an input signal for PIP/PBP. (VGA/DVI-D 1/DVI-D 2/DP (DisplayPort)/HDMI/Composite/Component)
