Dell 2709W Monitor User Manual

Page 21

Auto Select

VGA

DVI-D 1 & 2

DisplayPort

HDMI

Component

Composite

Back

Scan for Sources. Press

to scan for available input signals.

Select VGA input when you are using the analog (VGA) connector. Press

to select the VGA input source.

Select DVI-D input when you are using the Digital (DVI) connector. Press

to select the DVI input source.

Select DisplayPort input when you are using DisplayPort connector. Press

to select the DisplayPort input source.

Select HDMI input when you are using HDMI connector. Press

to select the HDMI input source.

Select Component input when you are using component video connector. Press

to select the component input source.

Select Composite input when you are using composite video connector. Press

to select the composite input source.

Press

to go back to the main menu.

Color Settings

Allows you to set the image mode and color format.

Image mode submenu for VGA/DVI-D input
