Spare Parts List
SG-1SG/SG-1SF SG-1LG/SG-1LF SG-2LG/SG-2LF
No. Description QTY Part NO. QTY Part NO. QTY Part NO.
1 TOP COVER (LID) 1 NA 1 NA 2 NA
2 MAIN HANDLE (LARGE) 1 08068 1 08062 2 08080
3 ELEMENT FIXING PLATE (UPPER) 1 NA 1 NA 2 NA
4
REAR SPRING COVER (SHEET
METAL)
1 NA 1 NA 2 NA
5 HEATING ELEMENT (UPPER) 1 08069 1 08063 2 08081
6
CAST PLATE (UPPER)-flat
CAST PLATE (UPPER)-rib
1 NA 1 NA 2 NA
7
CAST PLATE (LOWER)-flat
CAST PLATE (LOWER)-rib
1 NA 1 NA 1 NA
8 HINGE 1 08070 1 08064 2 08082
9 PLATE CONNECTING SPRING 1 08074 1 08074 2 08074
10 HEATING ELEMENT (LOWER) 1 08071 1 08065 2 08083
11 INSULATION CLAMP (LOWER) 1 NA 1 NA 1 NA
12 MAIN BODY (BODY WRAP) 1 NA 1 NA 1 NA
13 CORD AND PLUG 1 08055 1 08047 1 08047
14 CERAMIC TUBE (INSULATOR) 3 08077 3 08077 5 08077
15 INSULATION （LOWER） 1 NA 1 NA 1 NA
16 BASE PLATE (LOWER) 1 NA 1 NA 1 NA
17 FEET 4 08075 4 08075 4 08075
18 THERMOSTAT 1 08078 1 08078 2 08078
19 THERMOSTAT DIAL 1 08041 1 08041 2 08041
20 PILOT LIGHT 1 08032 1 08067 2 08067
21 ON/OFF SWITCH 1 08054 1 08054 2 08054
22 DRIP TRAY (GREASE TROUGH) 1 08072 1 08066 1 08084
23 ELEMENT FIXING PLATE (LOWER) 1 NA 1 NA 2 NA
24 SMALL HANDLE (FRONT) 1 08076 1 08076 2 08076
25 INSULATION CLAMP (UPPER) 1 NA 1 NA 2 NA
26 INSULATION （UPPER） 1 NA 1 NA 2 NA
27 ADUSTABLE BRACKET SCREW 1 08088 1 08088 2 08088
28 ADUSTABLE BRACKET 1 08087 1 08087 2 08087
29 SPRING 1 NA 1 NA 2 NA
*NA = not available except by special order.
