19 TMDS Ground
20 Floating
21 Floating
22 TMDS Ground
23 TMDS Clock+
24 TMDS Clock-
Plug and Play Capability
You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display Identification Data (EDID)
using Display Data Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. Most monitor installations are automatic; you can select different
settings if desired. For more information about changing the monitor settings, see Operating the Monitor .
Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available on the left side of your monitor.
NOTE: This monitor supports High-Speed Certified USB 2.0 interface.
Transfer Speed Data
Rate
Power Consumption
High speed 480 Mbps 2.5W (Max, each port)
Full speed 12 Mbps 2.5W (Max, each port)
Low speed 1.5 Mbps 2.5W (Max, each port)
USB Upstream Connector
Pin Number 4-pin Side of the Connector
