Dell E198WFP Monitor - Manual (Page 13)

1. Turn off your computer and disconnect the power cable.
2. Connect either the white DVI or the blue VGA cable to the connectors on the computer and the monitor.
3. Connect the power cable.
4. Turn on your monitor and computer. If you do not see an image, push the input select button and ensure the correct input source is selected. If you still do not see an
image, see Troubleshooting your monitor .
Using the Front Panel
Use the buttons on the front of the monitor to adjust the image settings.
The following table describes the front panel buttons:
Input select
Use the Input Select button to choose between two different video signals that may be connected to your monitor.
NOTE: The floating 'Dell Self-test Feature Check' dialog appears on a black background if the monitor cannot
sense a video signal. Depending upon the selected input, one of the dialogs shown below will scroll continually.
