22  Setting Up the Monitor Setting Up the Monitor  23
Connecting the White DVI Cable Setting Up the Monitor
Attaching the Stand
NOTE: The stand is detached from monitor when it is shipped from the
factory.
NOTE: This is applicable for a monitor with a stand. When any other
stand is bought, please refer to the respective stand setup guide for set
up instructions.
Connecting the Blue VGA Cable
To attach the monitor stand:
1. Remove the cover and place the monitor on it.
2. Fit the two tabs on the upper part of the stand to the groove on the
back of the monitor.
3. Press the stand till it snaps into its place.
Connecting Your Monitor
WARNING: Before you begin any of the procedures in this section,
follow the
Safety Instructions .
To connect your monitor to the computer:
1. Turn off your computer and disconnect the power cable.
2. Connect either the white (digital DVI-D) or the blue (analog VGA) or
the black (DisplayPort) display connector cable to the corresponding
video port on the back of your computer. Do not connect both
cables on the same computer. Use both the cables only when they
are connected to two different computers with appropriate video
systems.
Connecting the black DisplayPort Cable
CAUTION: The graphics are used for the purpose of illustration only.
Appearance of the computer may vary.
