Replacing the Control Panel
1. Insert the control panel tab into the notch on the chassis.
2. Ensure that the control panel lever is secured by the tab on the chassis.
3. Connect the control panel cable to the connector on the system board.
4. Replace the computer cover.
5. Connect your computer and devices to electrical outlets, and turn them on.
Back to Contents Page
3 notch
4 system board connector
1 control panel lever
2 control panel tab
3 notch
NOTICE: To connect a network cable, first plug the cable into the network wall jack and then plug it into the computer.
