enGIne tank™ 48 tank™ 60 tank™ m48-kw tank™ m54-kh
Engine type 23 hp* Kohler
®
v-Twin ohv 25 hp* Kohler
®
v-Twin ohv 23 hp* Kawasaki ® v-Twin ohv
27 hp* Kohler
®
command
®
v-Twin ohv
Engine displacement/orientation 674cc/vertical 725cc/vertical 675cc/vertical 725cc/vertical
Engine fuel • gas •
Ignition • Transistor controlled •
Lubrication/filter • full pressure w/spin-on oil filter •
cooling system • Air •
Air cleaner • heavy-duty remote-mounted replacement dual element •
Alternator • 12v – 15 amp. regulated •
fuel capacity Twin 5-gallon tanks Twin 5-gallon tanks Twin 7-gallon tanks Twin 7-gallon tanks
dRIVe sYstem
Drive system
Kanzaki DUp-10 pumps & white ®
wheel motors
Kanzaki DUp-10 pumps & parker
wheel motors
Dual hydro-gear™ pK-12 pumps &
parker wheel motors
Dual hydro-gear™ pK-12 pumps &
parker wheel motors
ground speed fwd: 10 mph/rev: 5 mph fwd: 10 mph/rev: 5 mph fwd: 12 mph/rev: 5 mph fwd: 12 mph/rev: 5 mph
hydraulic fluid • rimula ® — 15w40 •
hydro fluid capacity 2.5 qt. 2.5 qt. 3 qt. 3 qt.
hydraulic oil filter • standard •
controls • 3-way adjustable lap bars •
Lap bar dampers • standard •
return to neutral • standard •
braking/parking brake • Dynamic/Knott drum •
steeRInG
caster wheel pivot bearings sintered self-lubricating sintered self-lubricating Timken ® roller, greasable Timken ® roller, greasable
front axle • pivoting/fixed with lockout pins •
chassIs
frame • fully welded steel 2" square tubing •
tIRes
front tire size 13" x 5" – 6" (smooth) 13" x 5" – 6" (smooth) 13" x 6.5" – 6" (smooth) 13" x 6.5" – 6" (smooth)
rear tire size 23" x 9.5" – 12" (turf) 23" x 9.5" – 12" (turf) 23" x 9.5" – 12" (turf) 24" x 12" – 12" (turf)
dImensIOns
Length x width x height 74" x 59" x 40.5" 78" x 71" x 40.5" 74.5" x 59" x 72" 78" x 65" x 72"
wheelbase 44.5" 48.5" 44.5" 50.5"
front track width 40" 44" 40.25" 45.5"
rear track width 45.5" 46.5" 45.5" 52"
weight (approx.) 995 lbs. 1,035 lbs. 1,080 lbs. 1,100 lbs.
mOwInG deck
Deck size/type 48" sloped-nose design 60" sloped-nose design 48" select cut system™ 54" select cut system™
Deck style/system • floating •
Deck blades • 3-blade •
Deck construction
10-gauge fabricated with
7-gauge reinforcements
10-gauge fabricated with
7-gauge reinforcements
10-gauge fabricated with
7- and 10-gauge reinforcements
10-gauge fabricated with
7- and 10-gauge reinforcements
Deck wash • patented smartJet™ high-pressure deck washing system •
Deck lift foot lever, spring assisted foot lever, spring assisted Dual pedal, spring assisted Dual pedal, spring assisted
Deck height adjustment • 1" – 5" (in .25" increments) •
blade spindle construction • cast-aluminum •
Deck pTo • Electronic fingertip engagement •
front anti-scalping
wheels/nose roller
2, greasable/1 nose roller 2, greasable/1 nose roller 4 standard, greasable 4 standard, greasable
rear anti-scalping rollers/striper • full width, adjustable •
addItIOnaL specIFIcatIOns
rops • standard, foldable •
Monitor/hour meter • standard, electronic •
seat type high-back, lever adjustable suspension high-back suspension seat, foldable, fully adjustable with armrests
cup holder • standard •
storage pouch • standard •
rear bumper and hitch • heavy-duty rear bumper w/bolt-on hitch standard •
waRRantY †
2-year limited commercial 2-year limited commercial 3-year limited commercial 3-year limited commercial
*as rated by engine manufacturer † See your local Cub Cadet Commercial Independent Dealer for warranty details. Commercial products are intended for professional use.
