DMX Channel Values
Channel Value Function
1
000

015
016

091
092

135
136

195
196

255
Strobe
Gobo Stopped
Adjacent gobo strobe: Slow > Fast
Adjacent color strobe: Slow > Fast
Adjacent color and gobo strobe: Slow > Fast
Gobo Bounce
™: Slow > Fast
2
000

007
008

015
016

023
024

031
032

039
040

047
048

055
056

063
064

071
072

079
080

087
088

095
096

103
104

111
112

119
120

127
128

255
Gobo
Blackout
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo 8
Gobo 9
Gobo 10
Gobo 11
Gobo 12
Gobo 13
Gobo 14
Gobo Spin: Slow > Fast
3
000

010
011

012
022

023
033

034
044

045
055

065
066

076
077

087
088

098
099

109
110

120
121

127
128

255
Color
Open/White
Red
Dark Blue
Yellow
Green
Pink
UV
Cyan
Orange
Magenta
Tri-Color (Red-White-Blue)
Quad-Color
Color Spin: Slow > Fast
4
000

255
Pan or Barrel Orientation
0
°
- 180
°
000

255
Tilt (DMX-605A)
0
°
- 90
°
5
000

120
121

136
137

245
246

255
Barrel Rotation (DMX-610A)
360
° clockwise rotation: Fast > Slow
Stop
360
° counter
-clockwise rotation: Slow > Fast
Stop
