Caution

Do not obstruct the air vents.
Do not touch unit or lamps while hot.
No user serviceable parts inside, please refer to CHAUVET for service.

Power Connections

The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.

Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable

In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.

Technical Specifications

Power

120V~60Hz AC

230V~50Hz AC

Fuse

20mm Glass 3.15A Fast Blow

20mm Glass 1.6A Fast Blow

Lamps

1 x 120V 300W

Part No 64514

1 x 230V 300W

Part No 64516

Dimensions

203 x 254 x 254mm / 8in x 10in x 10in

Weight

3.6kg / 7.92lbs

User Information

(Please complete for your records)

Date Purchased:

/

/

Serial No:

Dealer Stamp:

Model: CH-209 ALIEN

Alien

CH-209

Users Guide

Please read these instructions carefully before use

World-wide Headquarters:

3000 North 29

th

Ct., Hollywood, Florida, USA, FL 33020

Tel: +1-954-929-1115 Fax: +1-954-929-5560

www.ChauvetLighting.com
