Mini Tower/Slim Tower — Back Panel
Figure 3. Back Panel View of Mini Tower And Slim Tower
1. link-integrity light
2. network adapter connector
3. network-activity light
4. line-in connector
5. line-out connector 6. microphone connector
7. VGA connector
8. HDMI connector
9. USB 2.0 connectors (6)
Quick Setup
WARNING: Before you begin any of the procedures in this section, read the safety
information that shipped with your computer. For additional best practices
information, see www.dell.com/regulatory_compliance.
NOTE: Some devices may not be included if you did not order them.
1. Connect the monitor using only one of the following cables:
Figure 4. HDMI Connector
3
