Dell 2208WFP Monitor - Manual (Page 3)

Back View
Side View
Front panel controls
Label Description
1 Input Source select
2 OSD Menu/Select button
3 Brightness & Contrast/Down (-) button
4 Auto-adjust/Up (+) button
5 Power button (with power light indicator)
Back view Back View with monitor stand
Label Description
1
VESA mounting holes (100mm)
(Behind attached base plate) Use to mount the monitor.
2 Barcode serial number label
Refer to this lable if you need to contact Dell for
technical support.
3 Security lock slot
Use a security lock with the slot to help secure your
monitor.
4 Dell Soundbar mounting brackets Attach the optional Dell Soundbar.
5 Regulatory rating label Lists the regulatory approvals.
6 Stand removeal button Press to release the stand.
7 Cable management hole Help organize cables by placing them through the hole.
8 Lock down/release button
Push the monitor down, press the button to unlock the
monitor, and then lift the monitor to the desired height.
