28
50-inch Decks
•
To ease in removing the belt in later steps, loosen,
but do not remove, the bolt which secures the
pivoting idler pulley to the idler bracket.
See Figure 23.
Figure 23
•
Insert a 3/8”-drive ratchet wrench (set to tighten)
into the square hole found in the idler bracket on the
left side of the deck’s surface. See Figure 23.
•
Grasp the ratchet’s handle and pivot it toward the
tractor’s right side to relieve tension on the belt.
•
With belt tension relieved, carefully remove the
belt from around the left-hand spindle pulley.
IMPORTANT:
Carefully allow the ratchet to pivot
rearward before removing it from the square hole.
All Models
•
Remove the deck belt from around all pulleys,
including the deck idler pulley(s) and the electric
PTO clutch.
NOTE:
The idler pulley(s) may have to be loosened,
but not removed, in order to remove the belt from
around them.
•
Route the new belts (deck belt first) as shown on
the following page.
•
Retighten idler pulley(s), if loosened earlier.
•
Remount the belt guards removed earlier.
3/8” Square Hole
Spring
Belt Guard
Idler Bracket
Pivoting Idler Pulley
