Memory Card Reader
Cards supported

• CompactFlash (CF) card
• Smart Media (SM) card
• xD-Picture (xD) card
• Memory Stick (MS) card
• Memory Stick Duo card
• Memory Stick PRO Duo card
• Memory Stick PRO (MSPRO) card
• Memory Stick PRO HG

(MSPRO HG) card

• SecureDigital (SD) card
• SecureDigital Card (SDHC) 2.0
• MultiMedia Card (MMC)
• MicroDrive (MD)

Video
Integrated

Intel

Graphics Media Accelerator HD

Discrete

PCI Express x16 card

Audio
Type

Integrated 7.1 channel, High Definition

audio with S/PDIF support

System Board Connectors
Memory

four 240-pin connectors

PCI

one 124-pin connector

PCI Express x1

two 36-pin connectors

PCI Express x16

one 164-pin connector

Power (system board)

one 24-pin EPS 12V connector
(ATX-compatible)

Processor fan

one 4-pin connector
