Quickspecs, Compaq storageworks library adapter

QuickSpecs
Compaq StorageWorks
Library Adapter
DA-10459
World Wide — Version 3 — February 8, 2001
1
M
O D E L S
Compaq StorageWorks™ Dual Channel PCI to Ultra HVD Host Bus Adapter for Compaq Tape Libraries
The Compaq StorageWorks Library Adapter provides direct SCSI connectivity to Compaq ProLiant™ servers for Compaq’s complete line of
DLT libraries.
Library Adapter
157299-B21
The Compaq StorageWorks Library Adapter comes complete with a controller, user’s guide / installation guide, SmartStart™ CD, Windows NT and
NetWare driver CD, and necessary configuration utilities.
O
V E R V I E W
Direct SCSI Connectivity to Compaq Differential Tape Libraries
The StorageWorks Dual Channel UWD Library Adapter provides a reliable SCSI interface to Compaq ProLiant servers for direct connectivity of Compaq
Differential Tape Libraries. This adapter provides two identical 16-bit Fast/Ultra differential isolated SCSI channels, using a single PCI slot, supporting up
to four Compaq 35/70 DLT drives (two drives per channel). The adapter transfers data at Ultra-SCSI data transfer speeds, up to 40 MB/s per channel.
The StorageWorks Library Adapter eliminates the need for the ProLiant Connectivity Kit option when configuring Compaq differential tape libraries to
ProLiant servers.
Storage Capacity
It supports two channels of up to two external Compaq DLT 35/70 or DLT 20/40 drives per channel (total of four drives per controller) with a maximum
rated storage capacity of 140 GB (native) per controller.
Compatibility
It is available for Compaq ProLiant PCI server configurations and FWD SCSI-2 or UWD SCSI-3 tape drives and tape libraries.
Compaq StorageWorks Dual Channel UWD Library Adapter
