Crestron QM-AMP3x80 Series QuickMedia™ 3-Channel Amplifiers
QM-AMP3x80 Physical Views
19.00 in
(48.26 cm)
18.52 in
(47.04 cm)
17.01 in
(43.21 cm)
1.96 in
(4.99 cm)
12.53 in
(31.82 cm)
AMP3x80SR
AMP3x80MM
NOTE: The rear panel of the AMP3x80MM, which has different connectors than
the AMP3x80SR, is shown on the bottom of the diagram. For a detailed view, refer
to “Hardware Hookup” on page 13.
Ports
All connections to the AMP3x80 are made through the ports on the rear panel. Refer
to the illustrations and descriptions that follow.
NOTE: Interface connectors for the NET and audio ports are provided with the
AMP3x80.
Operations Guide – DOC. 6272 QuickMedia™ 3-Channel Amplifiers: QM-AMP3x80 Series • 5
