Dell E5515H Monitor - Manual (Page 17)

About Your Monitor

17
Identifying Parts and Controls
Front View
1
1 IR Lens (with LED indicator)
Back View
CAN ICES-3 (B)/NMB-3(B) Service Tag:1NGTQV1 Express SVC code:359 576 607 7
S/N: CN-0 P2NYV-64180-46D-001T
REV A00 Manufactured Date: Jul. 2014
DELL Model No. : E5515Hc : 100-240V 50/60Hz 2.5A
The equipment must be connected to an earthed mains socket-outlet. L'appareil doit être branché sur une prise de courant munie d'une mise à la terre. Raheen Business Park Limerick Ireland www.dell.com Made in China
Flat Panel Monitor /Moniteur écran plat
CAN ICES-3 (B)/NMB-3(B) Service Tag:1NGTQV1 Express SVC code:359 576 607 7
S/N: CN-0 P2NYV-64180-46D-001T REV A00 Manufactured Date: Jul. 2014
DELL Model No. : E5515Hc : 100-240V 50/60Hz 2.5A
The equipment must be connected to an earthed mains socket-outlet. L'appareil doit être branché sur une prise de courant munie d'une mise à la terre. Raheen Business Park Limerick Ireland www.dell.com Made in China
Flat Panel Monitor /Moniteur écran plat
1
2
3
4
5
Back View with monitor stand
Label Description Use
1 VESA mounting holes (400
mm x 400 mm) Wall mount monitor using VESA-
compatible wall mount kit (400 mm x
400 mm).
2 Regulatory label Lists the regulatory approvals.
3 AC power connector To connect the monitor power cable.
4 Function buttons (For more
information, see Operating
the Monitor) Use the buttons on the back of the
monitor to adjust the image settings.
5 Security lock slot Secures monitor with security lock.
