16 Using Your Projector
NOTE: If you press the Power button while the projector is running, the "Press
Power Button to Turn off Projector" message appears on the screen. To clear the
message, press the Menu button on the control panel or ignore the message; the
message disappears after 5 seconds.
Adjusting the Projected Image
Raising the Projector Height
1 Press the Elevator button.
2 Raise the projector to the desired display angle, and then release the button to
lock the elevator foot into position.
3 Use the tilt adjustment wheel to fine-tune the display angle.
Lowering the Projector Height
1 Press the Elevator button.
2 Lower the projector, and then release the button to lock the elevator foot into
position.
1 Elevator button
2 Elevator foot
3 Tilt adjustment wheel
2
3 3
1
Dell 1409X
USB
Remote
RS-232 DVI-D In S-Video In Video In VGA - B
I
Audio Out Audio In VGA - A
Out
VGA - A
I
