Dell IN1940MW Display - Manual (Page 10)

Pixel pitch 0.2835 mm
Viewing angle
160° (vertical) typical, 170° (horizontal)
typical
Luminance output 250 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Faceplate coating Antiglare with hard-coating 3H
Backlight LED light bar system
Response Time 5 ms typical
Color depth 16.7 millions colors
Color Gamut 83% CIE1976 (typical)*
*[IN1940MW] color gamut (typical) is based on CIE1976 (83%) and CIE1931 (72%) test standards.
Resolution Specifications
Model Dell IN1940MW Monitor
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 50 Hz to 76 Hz (automatic)
Maximum preset resolution 1440 x 900 at 60 Hz
Supported Video Modes
Video display
capabilities (DVI
playback)
480i/480p/576i/576p/720p/1080i/1080P
(Supports HDCP)
Preset Display Modes
Display Mode
Horizontal
Frequency (kHz)
Vertical Frequency
(Hz)
Pixel Clock (MHz) Sync Polarity
(Horizontal/Vertical)
VESA, 720 x 400 31.5 70.1 28.3 -/+
VESA, 640 x 480 31.5 59.9 25.2 -/-
