Identifying parts and controls, Front view, Back view – Dell E1609WFP Monitor User Manual
Page 3
The Dell™ E1609W flat panel display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD). The monitors features include:
■ Dell E1609W has a 15.6-inch (395 mm) viewable area display.
■ 1366x768 resolution, plus full-screen support for lower resolutions.
■ Tilt capability.
■ Removable pedestal and Video Electronics Standards Association (VESA) 100mm mounting holes for flexible mounting solutions.
■ Plug and play capability if supported by your system.
■ On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
■ Software and documentation media which includes an information file (INF), Image color Matching File (ICM), and product documentation.
■ Energy Saver feature for ENERGY STAR® compliance
■ Asset Management Capable.
Identifying Parts and Controls
Front view
Back View
1. OSD menu button
2. Up button /Brightness and Contrast
3. Down button /Auto adjust
4. Power On/Off button (with LED indicator)
