Figure 11. Turning On Power
Specifications
NOTE: Offerings may vary by region. The following specifications are only those required by law to ship with your
computer. For more information regarding the configuration of your computer, click Start → Help and Support and
select the option to view information about your computer.
Power
Voltage 100 VAC to 240 VAC
Wattage 365 W/290 W/255 W
Input Current 5.0 A/4.4 A
Coin-cell battery 3 V CR2032 lithium coin cell
Maximum heat dissipation 4774.00 BTU/hr
NOTE: Heat dissipation is calculated by using the power supply wattage rating.
Physical Mini-Tower Small Form Factor
Height 360 mm (14.17 inches) 290 mm (11.41 inches)
Width 175 mm (6.88 inches) 92.6 mm (3.64 inches)
Depth 435 mm (17.12 inches) 312 mm (12.28 inches)
Weight (minimum) 8.4 kg (18.51 lb) 5.3 kg (11.68 lb)
Environmental
Operating Temperature: 5°C to 35 °C (41 °F to 95 °F)
Information para NOM (únicamente para México)
The following information is provided on the device described in this document in compliance with the requirements of
the official Mexican standards (NOM).
Voltaje de alimentación 100 VAC – 240 VAC
Frecuencia 50 Hz – 60 Hz
Consumo eléctrico 2.9 A
Voltaje de salida 19,50 V de CC
