Control Commands List
Command Description Header
(WORD) Address
Code
(BYTE) Size Of
The
Payload
(WORD) CRC16 For
The Entire
Packet
(WORD) MsG ID
(WORD) MsG Size
(WORD) Command
Code
(BYTE) Value
(BYTE) Comment
Power 0xefbe 0x10 0x0005 0xffc6 0x1111 0x0001 0x01
Menu 0xefbe 0x10 0x0005 0xbfc7 0x1111 0x0001 0x02
Up 0xefbe 0x10 0x0005 0x7e07 0x1111 0x0001 0x03
Down 0xefbe 0x10 0x0005 0x3fc5 0x1111 0x0001 0x04
Left 0xefbe 0x10 0x0005 0xfe05 0x1111 0x0001 0x05
Right 0xefbe 0x10 0x0005 0xbe04 0x1111 0x0001 0x06
R-sync 0xefbe 0x10 0x0005 0x7fc4 0x1111 0x0001 0x07
Source 0xefbe 0x10 0x0005 0x3fc0 0x1111 0x0001 0x08
Volume + 0xefbe 0x10 0x0005 0xfe00 0x1111 0x0001 0x09
Volume – 0xefbe 0x10 0x0005 0xbe01 0x1111 0x0001 0x0a
Zoom In 0xefbe 0x10 0x0005 0x7fc1 0x1111 0x0001 0x0b
Zoom Out 0xefbe 0x10 0x0005 0x3e03 0x1111 0x0001 0x0c
Mute 0xefbe 0x10 0x0005 0xffc3 0x1111 0x0001 0x0d
Freeze 0xefbe 0x10 0x0005 0xbfc2 0x1111 0x0001 0x0e
Hide 0xefbe 0x10 0x0005 0x7e02 0x1111 0x0001 0x0f
Video Mode 0xefbe 0x10 0x0005 0x3fca 0x1111 0x0001 0x10
H. Keystone Up 0xefbe 0x10 0x0005 0xfe0a 0x1111 0x0001 0x11
H. Keystone Down 0xefbe 0x10 0x0005 0xbe0b 0x1111 0x0001 0x12
V. Keystone Up 0xefbe 0x10 0x0005 0x7fcb 0x1111 0x0001 0x13
V. Keystone Down 0xefbe 0x10 0x0005 0x3e09 0x1111 0x0001 0x14
Aspect Ratio (4:3/16:9) 0xefbe 0x10 0x0005 0x7e08 0x1111 0x0001 0x17 Toggle
Power Off 0xefbe 0x10 0x0005 0x3e0c 0x1111 0x0001 0x18
Source-VGA Analog 0xefbe 0x10 0x0005 0xffcc 0x1111 0x0001 0x19
Source-S-Video 0xefbe 0x10 0x0005 0xbe1f 0x1111 0x0001 0x22
Source-Composite 0xefbe 0x10 0x0005 0x7fdf 0x1111 0x0001 0x23
Key Pad Lock On 1 0xefbe 0x10 0x0005 0x3e1d 0x1111 0x0001 0x24
Key Pad Lock Off 2 0xefbe 0x10 0x0005 0xffdd 0x1111 0x0001 0x25
ECO Mode On 0xefbe 0x10 0x0005 0xbfd9 0x1111 0x0001 0x2a
ECO Mode Off 0xefbe 0x10 0x0005 0x7e19 0x1111 0x0001 0x2b
Auto Source On 0xefbe 0x10 0x0005 0x3fdb 0x1111 0x0001 0x2c
Auto Source Off 0xefbe 0x10 0x0005 0xfe1b 0x1111 0x0001 0x2d
Factory Reset 0xefbe 0x10 0x0005 0xbe1a 0x1111 0x0001 0x2e
Lamp Hour 0xefbe 0x10 0x0005 0x7fda 0x1111 0x0001 0x2f
Firmware Version 0xefbe 0x10 0x0005 0x3e12 0x1111 0x0001 0x30
Enter key 0xefbe 0x10 0x0005 0x3ff6 0x1111 0x0001 0x40
Key Pad Lock State 3 0xefbe 0x10 0x0005 0xffff 0x1111 0x0001 0x5d 0x01: Key Pad Lock On
0x00: Key Pad Lock Off
Unhide 4 0xefbe 0x10 0x0005 0x3fed 0x1111 0x0001 0x64
Get Hide State 5 0xefbe 0x10 0x0005 0xfe2d 0x1111 0x0001 0x65 0x00: Unhide
0x01: Hide
System Status 6 0xefbe 0x10 0x0005 0x7e46 0x1111 0x0001 0xff 0x01: Standby
0x02: Warm Up
0x03: Power ON
0x04: Cooling
0x05: Power Saving
Note 2: Response and control codes (remarked a superscript as 1~6) added to projector in firmware version 2.3 and
above.
