Dell

™ 2400MP RS232 Protocol Document

RS232 Projector Pin Assignment (Facing Projector)

RS232 Serial Communication Cable Pin Assignment (Facing Cable)

Pin Assignments

RS232 PIN DESCRIPTION

MINI DIN-6

1

2 TXD

5

3 RXD

3

4

5 GROUND 1,

2

6

7 Not

Used

6

8 Not

Used

4

9

Note 1: The RS232 cable is not provided by Dell.

RS232 Protocol
Communication Settings

Command Types
To display the OSD menu and adjust the settings.

Connection Settings

Value

Baud Rate

19200 bps

Data Bits

8 bits

Parity None
Stop Bits

1 bit

Flow control

None
