Dell 1909W Flat Panel Monitor User's Guide

file:///T|/htdocs/monitors/1909W/en/ug/operate.htm[11/8/2012 2:54:10 PM]

2. Power indicator
3. Headphone connectors

Using the Tilt, Rotation

NOTE:

This is applicable for a monitor with a stand. When the OptiPlex

TM

USFF 780/ OptiPlex

TM

SFF 980 AIO stand is bought, please refer to the respective AIO stand setup guide for set

up instructions.

Tilt

With the built-in pedestal, you can tilt the monitor for the most comfortable viewing angle.

NOTE:

The stand is detached when the monitor is shipped from the factory.

Rotating the Monitor

Before you rotate the monitor, your monitor should be fully vertically extended (

Vertical Extension

) and fully tilted (

Tilt

) up to avoid hitting the bottom edge of the monitor.
