Setting Up the Monitor

19

Wall Mounting (Optional)

(Screw dimension: M4 x 10 mm). Refer to the instructions that
come with the VESA-compatible base mounting kit.

1. Place the monitor panel on a soft cloth or cushion on a stable

flat table.

2. Remove the stand.
3. Attach the mounting bracket from the wall mounting kit to the

LCD.

4. Mount the LCD on the wall by following the instructions that

came with the base mounting kit.

NOTE: For use only with UL-listed wall-mount bracket with
minimum weight/load bearing capacity of 2.29 kg .
