Speaker Assemblies
Dell™ Latitude™ C540/C640 Service Manual
Removing the Speaker Assemblies
NOTICE: Disconnect the computer and any attached devices from electrical outlets, and remove any installed
batteries.
NOTICE: To avoid ESD, ground yourself by using a wrist grounding strap or by touching an unpainted metal surface on
the computer.
NOTICE: Read " Preparing to Work Inside the Computer " before performing the following procedure.
The speakers are located on the front left and right sides of the bottom case. As you remove the speakers, take note of the
speaker assembly orientations and the antenna wire routing under the routing clips.
