Using Your Studio Slim 540s

Front L/R line-out connector —

Connects to headphones and speakers

with integrated amplifiers.
On computers with a sound card, use the

connector on the card.

Microphone connector — Connects

to a record/playback device such as a

microphone, cassette player, CD player,

or VCR.
On computers with a sound card, use the

connector on the card.

Side L/R surround connector —

Connects to computers with 7.1 speakers,

and provides enhanced surround audio.
On computers with a sound card, use the

connector on the card.

HDMI 1.2 connector — Connects to a

TV for both audio and video signals.

NOTE: For a monitor without built-in

speakers, only the video signals will

be read.

USB 2.0 connector (4) — Connects

USB devices, such as a mouse, keyboard,

printer, external drive, or MP3 player.

VGA connectors — Connects to a

monitor or projector for video signals.

12 S/PDIF connectors — Connects to

amplifiers and TVs for digital audio through

coaxial digital cables. This format carries

an audio signal without going through an

analog audio conversion process.
